ME Series Double Mast Aluminum Aerial Work Platform — ME1000-2
The ME1000-2 reaches 12 m working height with 200 kg platform capacity on a 1.5×0.7 m platform. Upgraded to 1.5kw AC lifting motor, 2.6×2.32 m outrigger footprint, AC power (optional DC 24V/48V), and forklift slot — for demanding high-reach indoor maintenance and construction access.
Description
Product Description
ME Series Double Mast Aluminum Aerial Work Platform — ME1000-2
Overview
The Chenlift ME1000-2 is a double mast aluminum aerial work platform reaching 12 m working height with 200 kg platform capacity on a 1.5×0.7 m platform. Stepping up to a 1.5kw AC lifting motor (1.2kw DC motor) for the increased height demand, the ME1000-2 maintains the same 2.6×2.32 m outrigger footprint as the ME900-2 for consistent stability. AC supply (380V/220V/110V) is standard with optional DC 24V or 48V (24V/103Ah battery, 24V/15A charger). At 765 kg (AC) / 860 kg (DC) machine weight with 1.76 m stowed length and 1.03 m stowed width, it provides reliable high-reach access for indoor maintenance, construction, and facility management applications.
ME1000-2 Key Specifications
| Specification | ME1000-2 |
|---|---|
| Lift Capacity | 200kg |
| Working Height Max | 12m |
| Platform Height Max | 10m |
| Stowed Length | 1.76m |
| Stowed Width | 1.03m |
| Stowed Height | 1.93m |
| Platform Size (L×W) | 1.5×0.7m |
| Outrigger Footprint | 2.6×2.32m |
| Ground Clearance | 0.05m |
| Lifting Motor (AC) | 1.5kw |
| Weight (AC) | 765kg |
| Weight (DC) | 860kg |
| DC Power Source | 24V/103Ah |
| DC Lifting Motor | 1.2kw |
| Charger | 24V/15A |
Standard Configurations
- AC Power Supply
- Auxiliary Lowering Device
- Emergency Stop Button both on Platform and Ground
- Safety Belt Lock
- Forklift Slot
- Anti-Dust Cover on Mast
Optional Configurations
- DC 24V or DC 48V or Manual Power
- DC Power with Voltage Meter, Battery Indicator and Hour Meter
- Hydraulic Power Pack
- Flame Explosion-Proof System
- Motorized Device with Horn
- Isolation Platform
- Anti-Collision Sensor
- Over Loading Sensor
- AC Power to Platform
- Air Tube to Platform
- Platform Working Light
- Outrigger Sensor
- Platform Positioning Laser Lights
- Manual Pump Power
- Horn on Platform
- Extension Platform
- Towing Type
Applicable Scenarios
Indoor Maintenance · Facility Management · Construction Sites · Warehouse & Logistics · Infrastructure Projects · Airport & Station
