FSEP Series Self-Propelled Aerial Order Picker — FSEP3-3.3
The FSEP3-3.3 steps up to 3300 mm platform height while remaining compact at 450 kg net weight and 760 mm overall width. Zero turning radius, drivable at full height, 300 kg capacity — the mid-entry self-propelled order picker for standard warehouse racking heights.
Description
Overview
FSEP Series Self-Propelled Aerial Order Picker — FSEP3-3.3
The Chenlift FSEP3-3.3 is a mid-entry model in the FSEP Series self-propelled aerial order picker range, delivering 3300 mm maximum platform height with 300 kg platform capacity on a 600×700 mm platform — reaching 600 mm higher than the FSEP3-2.7 for standard warehouse racking applications. At 450 kg net weight with a 2130 mm overall height, the FSEP3-3.3 remains compact and highly maneuverable in narrow-aisle environments. With zero turning radius for in-aisle positioning, proportional control, automatic braking, pothole protection, drivable operation at full height, and a 1620×760 mm footprint, powered by a 2×12V/100Ah battery with a 24V/15A charger. Suited for standard-height racking operations where a self-propelled unit delivers the speed and productivity advantages over manual push models.
FSEP3-3.3 Key Specifications
| Specification | FSEP3-3.3 |
|---|---|
| Max Platform Height | 3300mm |
| Platform Capacity | 300kg |
| Platform Size | 600×700mm |
| Ground Clearance | 40mm |
| Battery | 2×12V/100Ah |
| Charger | 24V/15A |
| Overall Width | 760mm |
| Overall Length | 1620mm |
| Overall Height | 2130mm |
| Net Weight | 450kg |
Standard Configurations
Platform and Ground Control, Proportional Control, Automatic Braking, Auxiliary Lowering, Emergency Stop Button both on Platform and Ground, Drivable at Full Height, Onboard Diagnostic System, Tilting Sensor with Alarm, Zero Turning Radius, Pothole Protection
Optional Configurations
AC Power to Platform, Platform Working Light, Extension Platform, Platform Positioning Laser Lights, Overloading Sensor, Chassis Protect Cover
Applicable Scenarios
Warehouse Order Picking · Distribution Centers · Narrow Aisle Racking · E-commerce Fulfillment · Retail Stockrooms · Inventory Replenishment
