HAJ Series Electric Articulating Boom Lift — HA24J Electric
The HA24J Electric reaches 26.2 m working height with 230 kg platform capacity on a 2.44×0.91 m platform. Upgraded to 80V/560Ah battery and 12kw lift motor, 360° continuous turntable, 10.2 m up-and-over clearance, 15.4 m working radius, and 45% gradeability — a high-reach model in the HAJ Electric Series for large-scale outdoor projects.
Description
Overview
HAJ Series Electric Articulating Boom Lift — HA24J Electric
The Chenlift HA24J Electric is a high-reach electric articulating boom lift delivering 26.2 m working height with 230 kg platform capacity on a 2.44×0.91 m platform. This model steps up to an 80V/560Ah battery with 4kw driving motor and 12kw lift motor, providing the increased power required for this height range. With 360° continuous turntable rotation, ±90° platform rotation, ±90° vertical jib rotation, 10.2 m up-and-over clearance, 15.4 m maximum working radius, and 45% gradeability on 4×2 drive, the HA24J Electric is engineered for large-scale construction, infrastructure, and industrial projects where high working height and continuous swing capability are required. At 15000 kg machine weight with 4.2 km/h stowed drive speed and 0.37 m ground clearance, it delivers stable and reliable elevated access on demanding outdoor job sites.
HA24J Electric Key Specifications
| Specification | HA24J Electric |
|---|---|
| Max Working Height | 26.2m |
| Max Platform Height | 24.2m |
| Max Up and Over Clearance | 10.2m |
| Max Working Radius | 15.4m |
| Platform Size | 2.44×0.91m |
| Length (Stowed) | 10.65m |
| Width (Stowed) | 2.48m |
| Height (Stowed) | 2.85m |
| Wheelbase | 3m |
| Ground Clearance | 0.37m |
| Platform Capacity | 230kg |
| Platform Rotation | ±90° |
| Turntable Rotation | 360° Continuous |
| Vertical Jib Rotation (Up/Down) | ±90° |
| Drive Speed (Stowed) | 4.2km/h |
| Gradeability (Stowed) | 45% |
| Max Working Angle | 5° |
| Turning Radius (Outside) | 4.87m |
| Drive and Steer | 4×2 |
| Battery | 80V/560Ah |
| Lift Motor Power | 12kw |
| Driving Motor Power | 4kw |
| Control Voltage | 12V |
| Weight | 15000kg |
Standard Configurations
Descent & Movement Alarms, Tilt Alarm, Horn, Platform and Ground Emergency Stops, Emergency Power Unit, Two-Wheel Brake System, Smart Speed Control, Two-Wheel Drive, Equal Proportion Automatic Leveling System, Proportional Joystick Controls, Drive Enable, Hour Meter, 355° Turntable Non-continuous Rotation, Positive Traction Two Wheel Drive, Full Speed Motor, Telematics Pre-Interface, Active Defense System, Harsh Environment Kits, Thumb Rocker Steer, Manual Emergency Recovery
Optional Configurations
Solid Non Marking Tires, Mechanical Anti-Extrusion Protection System, Air Tube Connection to Platform, Lithium Battery, Power Plus Generator, Aluminum Alloy and Insulated Working Platform, Cold-Resistant Fire-Resistant and Biodegradable Hydraulic Oil
Applicable Scenarios
Construction Sites · Infrastructure Projects · Outdoor Maintenance · Industrial Facilities · Bridge & Overpass · Airport & Logistics
