CAZ Series Towable Articulating Boom Lift — CAZE10 Electric
The CAZE10 is the compact entry-level electric model in the CAZ Series, delivering 12 m working height with 3.4 m working radius. 200 kg platform, 360° rotation, 60V/100Ah battery, just 1600 kg — the lightest zero-emission towable boom lift for indoor and emission-sensitive access in tight spaces.
Description
Overview
CAZ Series Towable Articulating Boom Lift — CAZE10 Electric
The Chenlift CAZE10 is the compact entry-level electric model in the CAZ Series towable articulating boom lift range, delivering 12 m maximum working height with 3.4 m working radius and 10.3 m maximum lifting height in zero-emission, low-noise operation. As the smallest and lightest electric model at just 1600 kg with a compact 3.7×1.95×2.9 m footprint, it is the most maneuverable option for indoor and emission-sensitive sites. Powered by a 60V/100Ah battery with a 1.5KW lifting motor and 2KW travel motor, with 200 kg platform load and 360° rotation, towable at 15–30 km/h. Equal proportion automatic leveling, proportional joystick controls, active defense system, and manual emergency recovery are standard — suited for indoor facility maintenance, shopping malls, and venues where clean, quiet operation is required.
CAZE10 Key Specifications
| Specification | CAZE10 |
|---|---|
| Max Working Height | 12m |
| Max Working Radius | 3.4m |
| Max Lifting Height | 10.3m |
| Rotation Angle | 360° |
| Platform Load | 200kg |
| Platform Size | 0.9×0.6m |
| Overall Size (L×W×H) | 3.7×1.95×2.9m |
| Lifting Speed | 0.05–0.09m/s |
| Working Pressure | 10MPa |
| Travel Speed | 15–30km/h |
| Wind Resistance | ≤5 |
| Lifting Motor | 1.5KW |
| Travel Motor | 2KW |
| Battery Pack | 60V/100Ah |
| Weight | 1600kg |
Standard Configurations
Descent & Movement Alarms, Tilt Alarm, Horn, Platform and Ground Emergency Stops, Emergency Power Unit, Two-Wheel Brake System, Smart Speed Control, Two-Wheel Drive, Equal Proportion Automatic Leveling System, Proportional Joystick Controls, Drive Enable, Hour Meter, 355° Turntable Non-continuous Rotation, Positive Traction Two Wheel Drive, Full Speed Motor, Telematics Pre-Interface, Active Defense System, Harsh Environment Kits, Thumb Rocker Steer, Manual Emergency Recovery
Optional Configurations
Solid Non Marking Tires, Air Tube Connection to Platform, Lithium Battery, Power Plus Generator, Aluminum Alloy and Insulated Working Platform, Cold-Resistant Fire-Resistant and Biodegradable Hydraulic Oil
Applicable Scenarios
Indoor Facility Maintenance · Shopping Malls & Venues · Signage & Lighting · Property Management · Emission-Sensitive Sites · Outdoor Access
