MX Series Self-Propelled Scissor Lift — MX1000S
The MX1000S reaches 11.80 m working height with 320 kg platform capacity on a 2.30×1.15 m deck. Asynchronous AC motor, zero inside turning radius, and drivable at full height — suited for large-scale industrial maintenance, infrastructure projects, and high-reach construction site operations.
Description
Product Description
MX Series Self-Propelled Scissor Lift — MX1000S
Overview
The Chenlift MX1000S is a high-reach self-propelled scissor lift delivering 11.80 m working height with 320 kg platform capacity on a 2.30×1.15 m deck. Zero inside turning radius and drivable at full height allow efficient repositioning at elevation, making the MX1000S suitable for large-scale industrial maintenance, infrastructure projects, and construction sites where both height and load capacity are critical requirements. The asynchronous AC motor and 4×6V/200AH power source ensure reliable sustained performance across extended work sessions.
MX1000S Key Specifications
| Specification | MX1000S |
|---|---|
| Platform Capacity | 320kg |
| Extension Capacity | 113kg |
| Working Height Max ❶ | 11.80m |
| Platform Height Max ❷ | 9.80m |
| Overall Length ❸ | 2.45m |
| Overall Width ❹ | 1.18m |
| Overall Height (Rails Up) ❺ | 2.48m |
| Overall Height (Rails Down) ❻ | 1.88m |
| Platform Size (L×W) | 2.30×1.15m |
| Platform Extension Size | 0.90m |
| Ground Clearance (Stowed) | 0.10m |
| Ground Clearance (Raised) | 0.02m |
| Wheelbase ❼ | 1.92m |
| Turning Radius (Inside) | 0 |
| Turning Radius (Outside) | 2.65m |
| Lift/Drive Motor | 24V/3.50kw |
| Travel Speed (Stowed) | 3.50km/h |
| Travel Speed (Raised) | 0.80km/h |
| Raise/Lower Time | 3–5m/min |
| Power Source | 4×6V/200AH |
| Charger | 24V/30A |
| Gradeability | 25% |
| Maximum Working Slope | 1.5°/3° |
| Tire Size | 380×127mm |
| Weight | 2750kg |
Standard Configurations
- Asynchronous AC Motor
- Proportional Control
- Extension Platform
- Automatic Brake System
- Forklift Slot
- Emergency Stop Button both on Platform and Ground
- Fault Diagnosis System
- Automatic Pothole Protection
- Drivable at Full Height
- Tilting Protection Sensor
- Maintenance Supporting Bar
- Auxiliary Lowering Device
Optional Configurations
- Platform Working Light
- AC Power to Platform
- Overloading Sensor
- Wireless Tracking
- Anti-Collision Sensor
- Air Tube to Platform
- Flame Explosion-Proof System
- Heavy Duty Pipe Rack
Applicable Scenarios
Warehouse & Logistics · Industrial Maintenance · Construction Sites · Infrastructure Projects · Facility Management · Airport & Station · Outdoor Operations
