MD Series Oil-Free Self-Propelled Vertical Lift — MD390-2
The MD390-2 is a full electric oil-free self-propelled vertical lift with 6 m working height and 230 kg lift capacity. CAN BUS protocol, drivable at full height, non-marking tires, and self-locking gates — built for cleanroom, metro, rail, and sensitive indoor environments.
Description
Product Description
MD Series Oil-Free Self-Propelled Vertical Lift — MD390-2
Overview The Chenlift MD390-2 is a full electric oil-free self-propelled vertical lift delivering 6 m working height with zero hydraulic oil. Built on CAN BUS protocol with proportional joystick control, it offers smooth and precise operation in environments where contamination risk must be eliminated — including metro rail tunnels, station platforms, cleanrooms, and food production facilities.
Key Specifications
| Specification | MD390-2 |
|---|---|
| Lift Capacity | 230kg |
| Platform Extension Capacity | 120kg |
| Max. Working Height ❶ | 6m |
| Max. Platform Height ❷ | 4m |
| Platform Size | 1.5×0.8m |
| Platform Extension | 0.4+0.4m |
| Stowed Length ❸ | 2.3m |
| Stowed Width ❹ | 0.8m |
| Stowed Height ❺ | 1.99m |
| Wheelbase | 1.11m |
| Ground Clearance | 0.07m |
| Travel Speed (Stowed) | 4Km/h |
| Travel Speed (Raised) | 0.8Km/h |
| Turning Radius (inside) | 0.5m |
| Turning Radius (outside) | 1.2m |
| Up/Down Speed | 20S/25S |
| Gradeability | 25% |
| Maximum Working Slope (Side/Width) | 1.5°/3° |
| Tyre | 305×100 |
| Battery | 2×12V/100Ah |
| Charger | 24V/30A |
| Total Weight | 920kg |
Standard Configurations
- Oil Free
- CAN BUS Protocol
- Proportional Joystick Control
- Self-Locking Gates
- Drivable at Full Height
- Non-Marking Tires
- Dual Wheel Automatic Braking
- Emergency Descent System
- Fault Diagnose System
- Tilt Alarm / Motion Alarm / Horn / Hour meter
- Extension Platform for both two sides
- Overloading Sensor
- Forklift Slot
- Pothole Protection
Optional Configurations
- AC Power to Platform
- Platform Working Light
- Platform Positioning Laser Lights
- Wireless Tracking
Applicable Scenarios Metro & Rail Tunnels · Station Platforms · Rolling Stock Depots · Cleanroom / Pharma · Food Production · Warehouse & Logistics · Indoor Maintenance
